Fuse classification.slow blow vs fast blow fuse

14

2023-07

美高梅体育ios版

According to size, it can be divided into

Dimensions, 3.6X10, 3X10, 5X20, 6X30, 6X32, 6X25, 10 * 38, 2.4X7, 2.5X6, 3X8, 2.5X9, 8.5X8, 8.5X8X4, 3.5X10, 3.5X9

According to current, it can be divided into

32ma, 63ma, 100mA, 150mA, 200mA, 250mA, 300mA, 400mA, 500mA, 600mA, 800mA, 1A, 1.25A, 1.6A, 2A, 2.5A, 3A, 3.5A, 4A,

5A, 6A, 7A, 8A, 9A, 10A, 12A, 15A, 20A, 25A, 30A

According to material classification, it can be divided into

Glass current fuse, ceramic current fuse
