High voltage fuse.battery charger fuse

21

2023-07

Share:

美高梅体育ios版

1. British standard fuse

British fuses are mainly used for equipment produced in Commonwealth countries. The British standard fuse case is made of ceramic material, and the product has the characteristics of small size and high cost-effectiveness, which is particularly favored by UPS manufacturers below 240V.

2. American standard fuse

American style fuses are the most widely used, covering most power electronic product applications. The American standard fuse case is made of melamine mesh cloth and ceramic lamination process, which has strong impact resistance, small Joule integral value, low power loss, superior DC performance and other characteristics, and is widely used in substations, Electric locomotive and other occasions.

3. European standard fuse

The shell of the European standard square fuse is made of ceramic material. This product has the characteristics of low operating temperature, low power loss, and small Joule integral value, and is suitable for applications that require compact structure, superior performance, and high power, especially in manual maintenance switches (MSDs) that are widely used.

4. Standard fuse

The French standard fuse has the characteristics of strong cycling performance, small size, and unique construction, which is suitable for small UPS, small AC drives, and other low-power applications with small space occupation
