Surface mount fuses can be divided into the following shapes based on their appearance and installation method:

1. Rectangle: This is the most common shape of surface mount fuses, usually with sizes such as 0402, 0603, 0805, etc. Rectangular patch fuses are suitable for various small electronic devices, such as mobile phones, tablets, etc.

2. Circular: This type of patch fuse is typically used in specific applications, such as circuits that require high voltage resistance or high current. The pin design of the circular patch fuse makes it more secure and reliable during soldering.

3. Alien: In order to meet the needs of special circuits, some surface mount fuses are designed in irregular shapes, such as L-shaped, U-shaped, etc. These irregular fuses have unique advantages in certain specific circuit layouts and can better adapt to complex design requirements.
